Confocal Laser Scanning Microscopy

  • Axiovert 200 M Inverted Research microscope
  • 3 Confocal detection channels
  • Laser lines [nm]
    • 405 Diode 30 MW
    • Argon multiline (458/477/488/514 30 MW)
    • 543 HeNe 10 MW
    • 594 HeNe 2 MW
    • 633 HeNe 5 MW
  • Objectives: "Type" magnification/numerical aperture, Working Distance
    • "Plan Apochromat" 5x/0.16, WD=12.1
    • EC "Plan Neofluar" 10x/0.30, WD=5.60
    • "Plan-Apochromat" 20x/0.80, WD=0.55
    • EC Plan "Neofluar" 40x/1.30 Oil DIC, WD=0.20
    • "C-Apochromat" 40x/1.20 W corr, WD=0.28
    • "Plan-Apochromat" 63x/1.40 Oil DIC, WD=0.18
    • "Plan-Apochromat" 100x/1.40 Oil DIC, WD=0.17
  • Mercury light source for fluorescence viewing
